| CNC TURNING & MILLING MACHINERY | |
| Mazak QT 20 with Auto Barfeed | 10" Dia. 17.75" Length |
| Mazak QT 20N | 12.5" Dia. 40" Length |
| Mazak QT 25 | 12.5" Dia. 39.4" Length |
| Mazak QT 28M with Auto Barfeed & Live Tooling | 16.25" Dia. 60" Length |
| Mazak QT 30 | 12.5" Dia. 39.4" Length |
| Mazak QT 35 | 19.5" Dia. 59" Length |
| Mazak V-10N Milling Center (3 Axis) | X 39" Y 19" Z 20" |
| Mazak VTC-20B Milling Center (4 Axis) | X 44" Y 20" Z 20" |
| CNC GEAR SHAPING & HOBBING: | |
| Mitsubishi - GD30 Hobber | 300mm (11.8") Max Diameter 8M/3.18P Max Module/Pitch |
| Fellows Corporation - 10/4 CNC Gear Shaper | 4" Stroke 12" Max Diameter |
| GEAR CUTTING: | |
| Fellows 6-A | 12" Diameter Shaper |
| Gleason No. 104 | Straight Bevel Coniflex Generator |
| (2) Jeil Hobber | Model JPS-2 Hobber |
| Brown & Sharpe | No. 3 Ratchet Machine |
| Gould & Eberhardt | 12H Hobber |
| (2) Nihonkikai Hobber | Model NDP-2 & NDP-1 Hobber |
| Barber-Colman 200 | Gear Shaper |
| Ratchet Machine | 6" Diameter |
| INSPECTION SYSTEMS: | |
| Roto-Technology - CNC Automatic Analytical Gear Inspection System RC-400 - Capacity 18" diameter: 30" between centers. | |
| M&M Pitch Diameter Measurement System ODA-12 Dimension Over Pins Cage - Readability +_0.0001" (+_0.0025mm) | |
| HOB & CUTTER CHECKER: | |
| Manufactured Gear & Gauge, Inc. - Hob & Cutter Sharpening Measuring Instrument H6-1000-1 - used to measure rake of flute, radial or hook and parallelism. It will accommodate a maximum tool diameter of eight (8") inches. | |
| GRINDING: | |
| Toyoda CNC Grinder 32X100N | 8.6" Dia. 39" Length |
| Landis Grinder 858-93 | 6" Dia. 18" Length |
| Heald Model 161 | Rotary Grinder |
| Parker Majestic Internal | 12" Dia. 16" Length |
| TOOL GRADING | |
| Barber Colman | 8" Dia. 12" Length |
| Barber Colman Automatic | 8" Dia. 12" Length |
| Gleason 104 Cutters #496 | 8" Diameter |
| Gleason Straight Cutter Grinder | 4" Cup Wheel |
| MANUAL LATHE: | |
| Langun Horizontal Mill | |
| Bridgeport Vertical Mill | |
| Warner Swasey 1-A Turret | 12" Diameter |
| Clausing Coldchester Engine Lathe | 17.25" X 48" Diameter |
| Southbend-Nordic | 8.75" Diameter |
| HONING: | |
| Sunnen MBB-1800 | 3.75" |
| Sunnen MBC-1802 | 3.75" |
| SAWS: | |
| DoAll - C80 | 12" Diameter |
| DoAll - 1213A | 10" Diameter |
| Marvel 6A Saw | 6" Diameter |
| KEYWAY MACHINE: | |
| LaPoint Hydraulic Pull | |
| Davis Key Seater Model 15 | |
